GMTO Pressure Transducer Basic Kit

Product Description

GMTO pressure transducer basic kit

Pressure Transducer for use with ATS5004D and ATS605004D and HS6DIFF oscilloscopes

Note this kit does not include adaptors for petrol or diesel engines in cylinder pressure testing or fuel pressure testing

Allows you to perform the following tests:

• Dynamic in cylinder pressure testing with the engine running or cranking.

  The waveform captured then allows you to perform an analysis of the cylinders compression, timing, valve condition, exhaust back pressure and more.

• Measure fuel pressures up to 45 bar
• And any other air or fluid pressure you wish to test up to 45 bar
• Not suitable for exhaust and intake pulsation tests, for this we recommend the APS260 Click here to see APS260

Features:

• Powered with 9 volt battery
• Timer control for switch on period which can be set to 10 minutes, 30 minutes or permanently on

Includes:

• Pressure transducer
• Carry case
